Isis Metals stands out as a top-notch manufacturer and supplier of **Copper Bars and Rods** right from the heart of Manila, Philippines. They’re known for delivering high-quality copper products that boast remarkable electrical and thermal conductivity, along with impressive corrosion resistance and durability. Thanks to their cutting-edge manufacturing technology and rigorous quality checks, Isis Metals guarantees that each copper bar and rod adheres to international standards for precision and performance. These products are crafted for a variety of uses in electrical, mechanical, and industrial settings, making them a reliable and versatile choice. Isis Metals proudly provides high-performance copper solutions to industries not just in the Philippines, but also in international markets.
When it comes to **Copper Bars and Rods**, they’re primarily made from high-purity copper (usually around 99.9% Cu) and may contain trace elements that boost strength, machinability, or oxidation resistance. This specific makeup ensures excellent electrical and thermal conductivity, high ductility, and outstanding corrosion resistance. Typically, the material has a tensile strength ranging from 210 to 250 MPa, and it can be easily fabricated, welded, and machined. Copper’s consistent properties across various environmental conditions make it a go-to choice for applications that demand both conductivity and durability.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Material | Copper |
| ETP GRADE | |
|---|---|
| Copper Hex Bar | ø 8 mm to 110 mm |
| Copper Round | ø 7 mm to 120 mm |
| Copper Square Bar | 10*10 mm to 90*90 mm |
| Electrical Conductivity: – (% IACS) | 98.5% min |
| Standards | BS EN 13601:2013, IS: 191, 1897 & 613 |
| Specifications | Cu : 99.90%, 02<400ppm |
| Copper Round Rod C101 | |
|---|---|
| 6.3mm (1/4″) | 38.1mm (1 1/2″) |
| 9.5mm (3/8″) | 30mm |
| 12.7mm (1/2″) | 25.4mm (1″) |
| 12mm | 25mm |
| 10mm | 20mm |
| 16mm | 19mm (3/4 |
| Diameter in mm | Weight in Kg/m |
|---|---|
| 8 | 0,447 |
| 6 | 0,252 |
| 9,5 | 0,631 |
| 12 | 1,007 |
| 11 | 0,846 |
| 60 | 25,164 |
| 12,5 | 1,092 |
| 14 | 1,370 |
| 42 | 12,330 |
| 13 | 1,181 |
| 70 | 34,251 |
| 16 | 1,789 |
| 80 | 44,736 |
| 38 | 10,094 |
| 35 | 8,563 |
| 50 | 17,475 |
| 40 | 11,184 |
| 20 | 2,796 |
| 19 | 2,523 |
| 22 | 3,383 |
| 28 | 5,480 |
| 30 | 6,291 |
| 25 | 4,369 |
| 32 | 7,158 |
| 45 | 14,155 |
| Molecular Weight | 63.55 |
|---|---|
| Boiling Point | 2567 °C |
| Melting Point | 1083.4 °C |
| Density | 8.96 g/cm3 |
| Electrical Resistivity | 1.678 microhm-cm @ 20 °C |
| Appearance | Reddish Metal |
| Young’s Modulus | 110–128 GPa |
| Solubility in H2O | N/A |
| Heat of Fusion | 3.11 Cal/gm mole |
| Electronegativity | 1.9 Paulings |
| Poisson’s Ratio | 0.34 |
| Heat of Vaporization | 72.8 K-cal/gm atom at 2567 °C |
| Tensile Strength | N/A |
| Specific Heat | 0.092 Cal/g/K @ 25 °C |
| Thermal Expansion | (25 °C) 16.5 µm·m-1·K-1 |
| Thermal Conductivity | 4.01 W/cm/K @ 298.2 K |
| Vickers Hardness | 369 MPa |
Yes, Copper Bars and Rods can be susceptible to galvanic corrosion when in contact with dissimilar metals, particularly in the presence of moisture or electrolytes. Proper insulation helps prevent this.
Yes, Copper Bars and Rods are fully recyclable. The material retains its properties after recycling, making it an eco-friendly choice for sustainable industrial applications and reducing environmental impact.
Yes, Copper Bars and Rods can be used for natural gas applications. They offer excellent corrosion resistance and conductivity, making them suitable for gas systems, provided they are properly maintained.
**Copper Bars and Rods** find their place in a wide array of sectors, including electrical, construction, and industrial fields. They’re perfect for crafting electrical conductors, bus bars, connectors, terminals, and grounding components. In mechanical and plumbing contexts, they’re utilized for valves, fasteners, and heat exchangers, thanks to their corrosion resistance and ease of shaping. Plus, they’re also used in decorative, architectural, and renewable energy projects. The blend of conductivity, workability, and longevity makes **Copper Bars and Rods** a favored material for a variety of engineering, electrical, and industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
