Isis Metals is a reputable manufacturer and supplier located in Manila, Philippines, focusing on top-notch Stainless Steel Hex Bars and Rods. Crafted for exceptional strength, precision, and resistance to corrosion, these products are perfect for a variety of industrial and structural uses. Isis Metals caters to vital sectors like construction, petrochemical, oil and gas, marine, and power generation. With cutting-edge manufacturing technology and a strong dedication to quality, the company guarantees that its Stainless Steel Hex Bars and Rods comply with international standards, delivering outstanding durability, dimensional accuracy, and performance even in the toughest environments.
Stainless Steel Hex Bars and Rods are primarily made up of chromium (16–20%), nickel (8–12%), along with trace amounts of carbon, manganese, silicon, and molybdenum, all balanced with iron. This unique blend provides them with remarkable resistance to corrosion and oxidation. On the mechanical side, they showcase impressive tensile strength (500–750 MPa), excellent yield strength, and good toughness across a range of temperatures. They retain their strength, ductility, and hardness even when under pressure. Additionally, Stainless Steel Hex Bars and Rods are resistant to pitting, crevice corrosion, and scaling, ensuring dependable performance in both high-temperature and corrosive industrial settings.
| Name | Stainless Steel Hexagonal Bars |
| Stainless Steel Hex Bar Standard | EN, AISI, DIN, ASTM, SUS |
| Grades | 304L, 201, 202, 301, 304LN, 309S, 17L, 347, 347H, 316N, 316LN, 304, 316, 316L, 317,3 304N 310S, 316Ti, |
| Stainless Steel Hex Bar Size (Hexagonal bar) | 6 x 6 milimeter to 75 x 75 milimeter |
| Shape | Stainless steel hexagonal bar |
| Price Term | CIF/FOB/CNF or as per need |
| Stainless Steel Hex Bar Length | 5MTR, 4MTR, 6MTR, 3MTR or as per need |
| Application | Architectural Applications, Kitchen Equipment , Sanitary Wares, Furniture, Precision Engineering |
| Stainless Steel Hex Bar Certificate | NDT Test Reports, NABL Approved Lab Test Reports, IGC Practice E Test Reports, Mill TC EN 10204 3.1, |
| Grade | Si | C | Mn | Cr | Ni | N | S | P |
| SS 304 | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 304L | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 316 | 0.75 max | 0.08 max | 2 max | 15 – 18 | 10 – 14 | 0.1 Max | 0.030 max | 0.045 max |
| SS 316L | 0.75 max | 2.00 max | 18.00 max | 14.00 Max | 0.10 Max | 0.1 Max | 0.030 max | 0.045 max |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Density | Melting Point |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 8.0 g/cm3 | 1454 °C (2650 °F) |
| SS 316L | 485 Min | 170 Min. | 40 % | 8.0 g/cm3 | 1400 °C (2550 °F) |
| Length in inch | Size in Inch | Weight (lbs/ft) |
|---|---|---|
| 144 | 1/4 | .180 |
| 3/8 | .415 | |
| 7/16 | .565 | |
| 1/2 | .735 | |
| 9/16 | .930 | |
| 5/8 | 1.15 | |
| 11/16 | 1.390 | |
| 3/4 | 1.655 | |
| 7/8 | 2.255 | |
| 1 | 2.945 | |
| 1-1/16 | 3.31 | |
| 1-1/8 | 3.73 | |
| 1-1/4 | 4.60 | |
| 1-3/8 | 5.58 | |
| 1-1/2 | 6.63 | |
| 1-5/8 | 7.78 | |
| 2 | 11.79 | |
| 4 | 47.160 |
| Sizes in Inch | Stainless Steel Hex Bar Sizes In inch |
| H-1/8 | 1/8 |
| H-1/4 | 1/4 |
| H-5/32 | 5/32 |
| H-3/16 | 3/16 |
| H-7/32 | 7/32 |
| H-5/16 | 5/16 |
| H-3/8 | 3/8 |
| H-7/16 | 7/16 |
| H-7/8 | 7/8 |
| H-1/2 | 1/2 |
| H-9/16 | 9/16 |
| H-5/8 | 5/8 |
| H-11/16 | 11/16 |
| H-3/4 | 3/4 |
| H-1 | 1 |
| H-1-1/8 | 1-1/8 |
| H-1-1/4 | 1-1/4 |
| H-2 | 2 |
| H-1-3/8 | 1-3/8 |
| H-1-1/2 | 1-1/2 |
| H-1-5/8 | 1-5/8 |
| H-1-3/4 | 1-3/4 |
| H-1-7/8 | 1-7/8 |
| H-2-1/4 | 2-1/4 |
| H-2-3/4 | 2-3/4 |
| H-2-1/2 | 2-1/2 |
| H-3 | 3 |
| Section | Size, diameter | Permitted overall variation | ||
| Class A | Class B | Class C | ||
| mm | mm | mm | mm | |
| Round | ≧ 6 <75 | 0.05 | 0.025 | 0.013 |
Stainless steel hex bars and rods come in various grades, including 304, 316, 410, 416, 420, and 630. They vary in corrosion resistance, strength, and hardness. Common types include austenitic, ferritic, martensitic, and precipitation-hardening stainless steels, each suited for different applications in manufacturing, construction, and marine environments.
In the Philippines, you can buy high-quality stainless steel (SS) hex bars and rods from suppliers such as Metal Supermarkets, 304 Stainless Steel, or Aalco Metals. They offer a wide selection of sizes and grades. Other reputable suppliers include Buy Metal Online, Steel Express, and Philippines Steel. Ensure to check their specifications for the exact product you need.
Yes, many Philippines suppliers offer 316 stainless steel hex bars and rods in custom sizes and finishes. Companies like Metal Supermarkets, Buy Metal Online, and Steel Express provide tailored options, including specific lengths, diameters, and polished finishes. Contacting the supplier directly allows you to request personalized products to meet your specific requirements for projects.
Stainless Steel Hex Bars and Rods from Isis Metals find extensive use in industries that demand high strength, precision, and corrosion resistance. In construction, they serve as frameworks, supports, and reinforcement components. The oil and gas sector utilizes them for valve parts, fasteners, and pump shafts. In the petrochemical and marine industries, they are perfect for components that come into contact with chemicals and seawater. Moreover, they are employed in power generation plants, food processing equipment, and machinery manufacturing. Their outstanding mechanical and anti-corrosive properties make them a reliable choice for various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
