Isis Metals stands out as a top-notch manufacturer and supplier of **Hastelloy C22 Forgings**, proudly based in Manila, Philippines. They specialize in crafting high-quality nickel-molybdenum-chromium alloys that are designed to offer exceptional corrosion resistance and mechanical performance. With cutting-edge forging technology and rigorous quality control measures, Isis Metals guarantees that every Hastelloy C22 Forging adheres to international standards for durability, reliability, and precision. These forgings are specifically engineered for challenging environments that are both corrosive and high-temperature, ensuring they perform excellently over the long haul in critical chemical, marine, and industrial applications. Isis Metals remains committed to providing reliable, high-performance alloy solutions for industries that need materials capable of withstanding the toughest conditions.
When it comes to **Hastelloy C22 Forgings**, the composition is primarily nickel (57–63%), molybdenum (12–14%), and chromium (20–22%), along with trace amounts of iron, tungsten, and cobalt. This carefully balanced alloy composition grants remarkable resistance to both oxidizing and reducing agents, as well as pitting, crevice corrosion, and stress-corrosion cracking. The material typically boasts a tensile strength of 690–760 MPa and retains excellent mechanical stability, even at higher temperatures. Hastelloy C22 is also known for its outstanding weldability, formability, and long-lasting corrosion resistance, making it a go-to choice for a variety of demanding industrial and chemical applications.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C22 Forging UNS (N06022), DIN (2.4602)
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V |
| Hastelloy C22 | Balance | 0.010 max | 12.5-14.5 | 0.50 max | 0.08 max | 2-6 | 0.02 max | 0.02 max | 2.5 max | 20-22.5 | 2.5-3.5 | 0.35 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000, MPa – 690 | Psi – 45000, MPa – 310 | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 |
Yes, Hastelloy C22 can be forged into custom shapes, as it has good formability and strength at elevated temperatures. However, it requires precise control during the forging process to maintain its properties.
The ideal temperature range for forging Hastelloy C22 is between 2,100°F (1,150°C) and 2,300°F (1,260°C). This ensures optimal formability and minimizes the risk of damaging the material's properties.
The forging process for Hastelloy C22 typically takes several minutes to hours, depending on the complexity and size of the part. The heating and cooling cycles also influence the total time required for forging.
**Hastelloy C22 Forgings** find their place in industries that require top-tier corrosion resistance and high-temperature performance. They are perfect for creating chemical processing equipment, reactor vessels, heat exchangers, and piping systems that come into contact with strong oxidizing and reducing agents. In marine and offshore sectors, you’ll find them used in valves, pumps, and fittings designed for seawater and brine applications. Additionally, Hastelloy C22 is utilized in pollution control equipment, power generation, and the pharmaceutical industry, where long-term reliability and resistance to harsh environments are essential. Its blend of durability and performance makes it a trusted choice across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
