Isis Metals is one of the leading manufacturers and suppliers in Manila, Philippines, for premium-quality Hastelloy Round Bars. Due to exceptional corrosion resistance, high strength and high ductility, our Hastelloy round bars offer a wide range of demanding industrial applications, particularly in chemical processing, in marine environments, and aerospace. We source our Hastelloy from the trusted suppliers with the goal to meet the highest industry standards in precision engineering and customer satisfaction. Our large inventory, experienced staff, and efficient logistics make us the preferred choice for businesses looking for reliable and cost-effective Hastelloy solutions in the Philippines and beyond. At Isis Metals, we strive to deliver superior performance and exceptional service to meet your industrial needs.
Hastelloy Round Bars are a nickel-molybdenum alloy with chromium and iron additions, which provides excellent corrosion resistance in aggressive environments. They possess good mechanical properties, such as high tensile strength, superior ductility, and remarkable creep resistance. These bars can resist temperatures up to 870°C (1600°F) and have a yield strength of about 310 MPa and tensile strength of more than 690 MPa. They provide excellent resistance against pitting, crevice corrosion, and oxidation, so it is quite favorable for applications involving chemical processing, marine, and aerospace. Its durability, plus machining ease, can ensure a high level of long-term reliability for demanding applications.
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
| STANDARD | UNS | WNR. | JIS | GOST | EN | OR |
|---|---|---|---|---|---|---|
| Hastelloy C276 | N10276 | 2.4819 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
| Hastelloy C22 | N06022 | 2.4602 | NW 6022 | – | NiCr21Mo14W | – |
| Hastelloy B2 | N10665 | 2.4617 | – | – | – | – |
| Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
|---|---|---|---|---|---|
| 7 x 7 | 0.337 | 19 x 19 | 2.479 | 38 x 38 | 9.916 |
| 8 x 8 | 0.44 | 20 x 20 | 2.747 | 40 x 40 | 10.988 |
| 9 x 9 | 0.556 | 21 x 21 | 3.029 | 42 x 42 | 12.114 |
| 10 x 10 | 0.687 | 22 x 22 | 3.324 | 45 x 45 | 13.906 |
| 11 x 11 | 0.831 | 24 x 24 | 3.956 | 48 x 48 | 15.822 |
| 12 x 12 | 0.989 | 25 x 25 | 4.292 | 50 x 50 | 17.168 |
| 13 x 13 | 1.161 | 26 x 26 | 4.642 | 53 x 53 | 19.29 |
| 14 x 14 | 1.346 | 28 x 28 | 5.384 | 55 x 55 | 20.774 |
| 15 x 15 | 1.545 | 30 x 30 | 6.181 | 60 x 60 | 24.723 |
| 16 x 16 | 1.758 | 32 x 32 | 7.032 | 65 x 65 | 29.015 |
| 17 x 17 | 1.985 | 34 x 34 | 7.939 | 70 x 70 | 33.65 |
| 18 x 18 | 2.225 | 36 x 36 | 8.9 | 75 x 75 | 38.629 |
Hastelloy round bars can undergo specific heat treatments, such as annealing, to enhance their mechanical properties and relieve stress. However, the exact process depends on the alloy grade and intended application.
Ensure the quality of Hastelloy Round Bars by sourcing them from reputable suppliers who adhere to industry standards like ASTM or ASME, and verify certifications like Mill Test Reports (MTR). Additionally, perform non-destructive testing (NDT) and inspect for dimensional accuracy and surface finish.
Yes, we provide Hastelloy Round Bars in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@isismetals.com
Hastelloy Round Bars are widely applied to industries that need materials withstanding critical conditions. In the petrochemical and chemical industries, they are applied to reactors, heat exchangers, evaporators, and distillation columns where corrosive chemicals are processed. In ocean environments, they are used in shafts, fasteners, and fittings because of their resistance to seawater corrosion. They find application in the aerospace industry in turbine parts, exhaust ducts, and high-temperature-exposed structural components. Hastelloy Round Bars are also applied in flue gas scrubbers, pollution control systems, and power generation equipment, where their strength and resistance to corrosion guarantee safe and effective operation.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
