Isis Metals is a reputable manufacturer and supplier of Incoloy Bright Bars located in Manila, Philippines. They offer top-notch nickel-iron-chromium alloy products that are celebrated for their outstanding corrosion resistance, strength, and sleek polished finish. These Incoloy Bright Bars are meticulously engineered to perform reliably even in tough chemical, high-temperature, and oxidizing environments. Isis Metals guarantees that each bright bar adheres to strict international quality standards, ensuring they are dimensionally accurate, durable, and built to last. These bars are perfect for various industries, including chemical processing, aerospace, marine, and power generation, where they provide exceptional mechanical performance, corrosion resistance, and reliability under demanding conditions.
The composition of Incoloy Bright Bars primarily includes nickel (30–45%), iron (40–50%), and chromium (20–30%), along with small amounts of copper, molybdenum, and titanium to boost their corrosion resistance, mechanical strength, and thermal stability. Mechanically, they showcase a tensile strength ranging from 600 to 850 MPa, along with excellent ductility, toughness, and a high resistance to stress corrosion cracking and oxidation at elevated temperatures. The bright polished finish not only enhances surface quality but also improves machinability and dimensional precision, making these bars ideal for critical applications that require both performance and visual appeal.
| Dimensions | BS, DIN, EN, AISI, JIS, ASME, ASTM |
|---|---|
| Size of Round Bars | Thickness: 2 milimeter-100 milimeter |
| Surface | Bright, Hot Rolled Pickled, Hairline, Cold Drawn, Sand Blasting Finished, Polished |
| Processing | cutting to 650 milimeter |
| Tolerance | H9, K9, H8, H12, K12, H11, H13, K10, K11, H10, or as per need |
| Finish | centreless ground, Cold (bright) drawn, smooth turned, hot rolled, slit rolled edge, peeled, Rough Turned, hot rolled annealed, Polish, Bright, Centreless Ground, Grinding & Black |
| Method | Cold Drawn, Hot Rolled, Cold Rolled Rod, Forged Round Bars |
| Condition | annealed, Hardened & tempered |
| Density | g/cm3 | 7.94 | |
|---|---|---|---|
| lb/in.3 | 0.287 | ||
| Melting Range | °F | 2475 – 2525 | |
| °C | 1357 – 1385 | ||
| Condition & Size | Tensile Strength | Yield Strength (0.2% Offset) | Elongation | Reduction of Area | Hardness |
|---|---|---|---|---|---|
| MPa, min | MPa, min | %, min | %, min | Rockwell, max | |
| Hot worked, as-hot-worked | 550 | 240 | 25 | … | … |
| Cold-worked and hot-worked, annealed | 515 | 205 | 30 | … | … |
| US Bar | Metric | Japanese | Canadian/ASTM | ||||
|---|---|---|---|---|---|---|---|
| Diam. (Inch) | Bar Size | Diam. (mm) | Bar Size | Diameter (mm) | Bar Size | Diameter (mm2) | Bar Size |
| 0.250 | #2 | 5 | 5 | 6 | 6 | 100 | 10M |
| 0.375 | #3 | 5.5 | 5.5 | 10 | 10 | 200 | 15M |
| 0.500 | #4 | 6 | 6 | 13 | 13 | 300 | 20M |
| 0.625 | #5 | 7 | 7 | 16 | 16 | 500 | 25M |
| 0.750 | #6 | 8 | 8 | 19 | 19 | 700 | 30M |
| 0.875 | #7 | 9 | 9 | 22 | 22 | 1000 | 35M |
| 1.000 | #8 | 10 | 10 | 25 | 25 | 1500 | 45M |
| 1.125 | #9 | 11 | 11 | 29 | 29 | 2500 | 55M |
| 1.250 | #10 | 12 | 12 | 32 | 32 | ||
| 1.375 | #11 | 14 | 14 | 35 | 35 | ||
| 1.500 | #12 | 16 | 16 | 38 | 38 | ||
| 1.625 | #13 | 18 | 18 | 41 | 41 | ||
| 1.750 | #14 | 20 | 20 | 44 | 44 | ||
| 1.875 | #15 | 22 | 22 | 48 | 48 | ||
| 2.000 | #16 | 25 | 25 | 51 | 51 | ||
| 2.250 | #18 | 28 | 28 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
| Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot | Size | kilogram / Meter | kilogram / Foot |
|---|---|---|---|---|---|---|---|---|
| 1/8″ | 0.062 | 0.019 | 22mm | 2.979 | 0.908 | 3-1/4″ | 41.996 | 12.800 |
| 3mm | 0.055 | 0.017 | 20mm | 2.470 | 0.753 | 3″ | 35.762 | 10.900 |
| 4mm | 0.098 | 0.030 | 24mm | 3.543 | 1.080 | 3-3/4″ | 55.780 | 17.001 |
| 5/32″ | 0.095 | 0.029 | 7/8″ | 3.038 | 0.926 | 3-1/2″ | 48.772 | 14.850 |
| 5mm | 0.154 | 0.047 | 1″ | 3.970 | 1.210 | 4-1/4″ | 72.249 | 21.908 |
| 3/16″ | 0.141 | 0.043 | 25mm | 3.871 | 1.180 | 4″ | 63.340 | 19.306 |
| 6mm | 0.223 | 0.068 | 27mm | 4.490 | 1.368 | 4-3/4″ | 90.249 | 27.366 |
| 7/32″ | 0.190 | 0.058 | 26mm | 4.170 | 1.271 | 4-1/2″ | 80.340 | 24.4487 |
| 7mm | 0.298 | 0.091 | 30mm | 5.548 | 1.691 | 5-1/2″ | 121.000 | 36.690 |
| 1/4″ | 0.249 | 0.076 | 1-1/8″ | 5.033 | 1.534 | 5″ | 99.940 | 30.461 |
| 8mm | 0.398 | 0.120 | 32mm | 6.314 | 1.894 | 6-1/2″ | 167.630 | 51.093 |
| 5/16″ | 0.387 | 0.118 | 1-1/4″ | 6.349 | 1.924 | 6″ | 143.900 | 43.860 |
| 3/8″ | 0.557 | 0.170 | 35mm | 7.553 | 2.390 | 7-1/2″ | 225.000 | 68.226 |
| 9mm | 0.498 | 0.152 | 1-3/8″ | 7.550 | 2.303 | 7″ | 196.000 | 59.432 |
| 11mm | 0.748 | 0.228 | 38mm | 8.903 | 2.792 | 10″ | 397.140 | 121.048 |
| 10mm | 0.620 | 0.189 | 36mm | 7.999 | 2.438 | 8″ | 254.55 | 77.586 |
| 12mm | 0.889 | 0.271 | 40mm | 9.872 | 3.009 | |||
| 7/16″ | 0.761 | 0.232 | 1-1/2″ | 8.951 | 2.715 | |||
| 13mm | 1.043 | 0.318 | 1-3/4″ | 12.179 | 3.712 | |||
| 1/2″ | 0.994 | 0.303 | 1-5/8″ | 10.449 | 3.200 | |||
| 9/16″ | 1.256 | 0.383 | 1-7/8″ | 13.977 | 4.260 | |||
| 14mm | 1.207 | 0.368 | 45mm | 12.555 | 3.807 | |||
| 5/8″ | 1.551 | 0.473 | 50mm | 15.414 | 4.698 | |||
| 15mm | 1.391 | 0.424 | 48mm | 14.205 | 4.330 | |||
| 17mm | 1.791 | 0.543 | 2-1/8″ | 17.963 | 5.475 | |||
| 16mm | 1.578 | 0.481 | 2″ | 15.906 | 4.848 | |||
| 18mm | 2.001 | 0.610 | 60mm | 22.205 | 6.768 | |||
| 11/16″ | 1.880 | 0.573 | 2-1/4″ | 20.128 | 6.135 | |||
| 3/4″ | 2.237 | 0.682 | 2-3/8″ | 22.435 | 6.838 | |||
| 2-1/2″ | 24.856 | 7.576 | ||||||
| 2-5/8″ | 27.409 | 8.354 | ||||||
| 2-3/4″ | 30.083 | 9.169 | – | – | – |
Incoloy bright bars offer excellent corrosion resistance, high-temperature strength, durability, oxidation resistance, and versatility in extreme environments.
Incoloy bright bars generally have excellent corrosion resistance due to their alloy composition, reducing the need for additional protective coatings. However, in highly aggressive environments, extra coatings or surface treatments may be applied for enhanced protection.
Incoloy Bright Bars find extensive use in industries that require components that are corrosion-resistant, high-strength, heat-resistant, and aesthetically pleasing. Typical applications include pump shafts, valve components, chemical processing equipment, heat exchangers, marine hardware, aerospace structural parts, and furnace components. They are also utilized in power generation, petrochemical, and desalination plants where exposure to corrosive environments and high temperatures is a significant concern. Isis Metals delivers Incoloy Bright Bars that ensure reliable performance, a long service life, and consistent quality for demanding industrial and engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
