Isis Metals stands out as a top manufacturer and supplier of Super Duplex Steel S32760 Bars and Rods, proudly based in Manila, Philippines. Known for their remarkable strength, resistance to corrosion, and long-lasting durability, these bars and rods are crafted to excel in tough environments. By utilizing high-quality raw materials and cutting-edge manufacturing techniques, Isis Metals guarantees precision, consistency, and adherence to international standards. The company provides a variety of sizes, shapes, and finishes for their Super Duplex Steel S32760 Bars and Rods, catering to industries like marine engineering, chemical processing, oil and gas, and power generation.
These bars and rods are made up of about 25% chromium, 7% nickel, and 3.6% molybdenum, along with additions of tungsten, copper, and nitrogen. This well-thought-out composition offers exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. On the mechanical side, they boast impressive tensile strength (≥750 MPa), yield strength (≥550 MPa), and excellent elongation (≥25%), merging the toughness of austenitic stainless steel with the strength of ferritic alloys. Their unique dual-phase microstructure enhances fatigue resistance, ensuring they perform exceptionally well under high pressure and temperature conditions.
| Standard | ASTM A276, ASME SA276 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 bars can be welded. However, it requires careful control of heat input and post-weld heat treatment to maintain its corrosion resistance and mechanical properties.
Super Duplex Steel S32760 rods are available in a wide range of sizes, typically from 6mm to 300mm in diameter. They can be supplied in various finishes, including hot-rolled, cold-drawn, and polished finishes.
Super Duplex Steel S32760 rods are highly resistant to galvanic corrosion due to their excellent corrosion resistance properties. However, if exposed to highly aggressive environments, the risk may increase when coupled with more anodic metals.
Super Duplex Steel S32760 Bars and Rods are extensively utilized in industries that require high strength and corrosion resistance. They are perfect for applications involving shafts, fasteners, pumps, valves, flanges, and heat exchangers in offshore, petrochemical, desalination, and marine settings. Their outstanding resistance to seawater, acids, and chloride-rich solutions makes them ideal for chemical process equipment and subsea components. These bars and rods promise long-lasting performance, lower maintenance needs, and high reliability in corrosive and high-stress operational environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
