Headquartered in Manila, Philippines, Isis Metals is a top steel and alloy product manufacturer and supplier of high-quality steel products with a specialty in Copper Nickel 70/30 Forgings. Isis Metals has a reputation for excellence in precision engineering, innovation, and customer satisfaction and caters to various industries, such as the marine, oil and gas, power generation, and chemical processing industries. Our Copper Nickel 70/30 forgings are well known for exceptional corrosion resistance, strength, and durability and are well suited to such applications as seawater piping, heat exchangers, and shipbuilding parts. Dedicated to delivering quality and performance, Isis Metals provides products that meet long-term reliability in harsh conditions.
Copper Nickel 70/30 Forgings are composed of about 70% copper and 30% nickel and contain small amounts of iron (0.4–1.0%) and manganese (0.4–1.0%) as additions to provide strength and corrosion resistance. The alloy exhibits superior seawater corrosion protection, biofouling resistance, and erosion. The mechanical properties commonly are tensile strength 310–483 MPa, yield strength 110–276 MPa, and elongation 20–40%, depending on the forging process. With a hardness of 80–150 HB, the alloy has superior toughness, ductility, and thermal stability, making it suitable for high-performance parts used in severe marine and industrial environments.
| Standard | DIN, ASTM, BS and all International Standards |
|---|---|
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70-30 | 65.0 min | 1 max | .05 max | 29-33 | 0.4-1.0 | 1 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Copper Nickel 70-30 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel 70/30 | 2.0882 | C71500 |
The durability of Copper Nickel 70/30 forgings is ensured by excellent corrosion resistance, high tensile strength, superior weldability, resistance to seawater, anti-biofouling properties, and consistent alloy composition for enhanced performance.
Copper Nickel 70/30 forgings offer superior strength, enhanced corrosion resistance, improved material utilization, reduced waste, better grain structure, and higher durability compared to machining, making them ideal for demanding applications.
Compatible welding processes for Copper Nickel 70/30 forgings include TIG (GTAW), MIG (GMAW), and shielded metal arc welding (SMAW), ensuring strong joints, excellent corrosion resistance, and minimal thermal distortion.
Copper Nickel 70/30 Forgings are used extensively in marine, industrial, and chemical applications because of their superior resistance to seawater corrosion and biofouling. They are utilized in shipbuilding for propellers, valves, pump parts, condenser plates, and heat exchangers. They are strong enough and durable to be used for seawater piping, hydraulic tubing, and offshore oil and gas platform structures. The superior mechanical and thermal properties of the alloy make them well suited for desalination plants, power generation systems, and chemical processing equipment. With a long life coupled with high-performance characteristics, Copper Nickel 70/30 Forgings provide reliability in the harshest working conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
