Headquartered in Manila, Philippines, Isis Metals is a reliable producer and distributor of quality steel and alloy materials, with specialization in Copper Nickel 90/10 Forgings. Known for its accurate engineering and quest for excellence, Isis Metals provides industries including marine, chemical processing, and power generation with high-quality metal solutions. Made up of 90% copper and 10% nickel, our Copper Nickel 90/10 forgings are renowned for their exceptional corrosion resistance, strength, and durability, which make them suitable for harsh conditions and seawater systems. Isis Metals is committed to delivering products that provide high performance, reliability, and long service life in challenging applications.
Copper Nickel 90/10 Forgings have 90% copper and 10% nickel, with a small amount of iron (Fe) and manganese (Mn) added to improve strength and corrosion resistance. The alloy provides tensile strength of 310–480 MPa, yield strength of 160–280 MPa, elongation of 30–50%, and Brinell hardness of 90–180 HB. It has good resistance to seawater corrosion, biofouling, and stress corrosion cracking, and good thermal conductivity, weldability, and formability. These characteristics render Copper Nickel 90/10 forgings highly resistant and trustworthy for key applications in the marine, power generation, and chemical processing sectors.
| Standard | ASTM B122, ASME SB122 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 90-10 | 88.6 min | 1.0 max | .05 max | 9-11 max | 1.8 max | 1 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Copper Nickel 90-10 | 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Copper Nickel 90/10 | 2.0872 | C70600 |
Copper Nickel 90/10 forgings may face challenges like higher cost, susceptibility to galvanic corrosion in specific environments, and limited availability in some sizes, requiring precise processing and material sourcing.
Common welding processes compatible with Copper Nickel 90/10 forgings include TIG (GTAW), MIG (GMAW), and SMAW. Proper filler materials, such as CuNi rods, ensure strong, corrosion-resistant welds for optimal performance.
Durability of Copper Nickel 90/10 forgings is ensured by factors like corrosion resistance, proper heat treatment, precise manufacturing, adequate welding techniques, and protection against galvanic corrosion in marine and industrial environments.
Copper Nickel 90/10 Forgings are popular throughout industries that require better corrosion resistance, strength, and durability. In the naval sector, they are critical in shipbuilding, seawater piping, pumps, valves, and heat exchangers, owing to their high resistance to biofouling and seawater corrosion. They also find application in power stations, desalination plants, and chemical works for parts like condensers, fittings, and heat exchangers. Featuring outstanding stress corrosion resistance, workability, and thermal conductivity, Isis Metals’ Copper Nickel 90/10 forgings ensure long-term performance in corrosive environments, providing safety, efficiency, and reliability in harsh engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
