Isis Metals stands out as a reliable manufacturer and supplier of Incoloy 800H Forgings right in Manila, Philippines. They provide top-notch forged components that are built for exceptional strength and heat resistance. Incoloy 800H is a unique nickel-iron-chromium alloy, enhanced with controlled amounts of carbon and aluminum-titanium to boost its performance at high temperatures. These forgings are known for their remarkable creep and rupture strength, along with excellent resistance to oxidation, carburization, and scaling, even in extreme heat. With a commitment to precision engineering and adherence to international standards, Isis Metals’ Incoloy 800H Forgings are perfect for sectors like chemical processing, power generation, heat treatment, and furnace component manufacturing.
Incoloy 800H Forgings are made up of Nickel (30–35%), Iron (the rest), Chromium (19–23%), plus small amounts of Aluminum (0.15–0.60%), Titanium (0.15–0.60%), and Carbon (0.05–0.10%). This alloy boasts a tensile strength of about 550 MPa, a yield strength of around 275 MPa, and an elongation of 30%, ensuring it can withstand thermal stress effectively. Incoloy 800H is particularly resistant to oxidation and corrosion at temperatures reaching up to 1100°C (2010°F), maintaining its structural integrity and mechanical strength even under intense heat and pressure.
Specifications ASTM B564 / ASME SB564, AMS 5766
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni | Fe | Cr | Cu | Ti | Al | C | Mn | S | Si |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | .15-.60 | .15-.60 | .05-.10 max | 1.5 max | .015 max | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | Psi – 30,000 , MPa – 205 | 30 – 35 % |
| Density | 0.287 lb/in3 / 7.94 g/cm3 |
| Melting Point | 2475 – 2525 °F/ 1357 – 1385 °C |
| Specific Heat @ 70°F | 0.11 Btu/lb•°F |
| Permeability @ 70°F Annealed | 1.014 (200 Oersted) |
| Curie Temperature | -115 °C/ -175 °F |
| Elastic Modulus | 28.50 X 106 psi |
| Electrical Resistivity @ 70°F | 595 ohm•circ mil/ft |
| Annealling Incoloy 800 | 983 – 1038 °C / 1800 – 1900 °F |
| Annealling Incoloy 800H / Ht | 1147 – 1177°C / 2100 – 2150 °F |
| Quench | Rapid Air / Water |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
The ideal temperature range for forging Incoloy 800H is between 2100°F and 2250°F (1149°C to 1232°C). This range ensures optimal workability and preserves the material’s mechanical properties.
Post-forging operations for Incoloy 800H typically include annealing to relieve stress and enhance ductility, followed by heat treatment to achieve desired mechanical properties. Surface cleaning and inspection for defects are also essential to ensure quality.
To determine if Incoloy 800H Forgings meet your specific needs, review material specifications, including composition and mechanical properties, and consult with suppliers for customized testing or performance data. Additionally, consider your application's temperature, corrosion, and mechanical requirements.
Incoloy 800H Forgings find their place in a variety of applications, including heat exchangers, furnace components, pressure vessels, and power generation systems. Their excellent resistance to high-temperature oxidation and carburization makes them a go-to choice for petrochemical processing, refinery heaters, and industrial boilers. They’re also utilized in steam superheaters, heat-treating fixtures, and components for nuclear power plants, where maintaining thermal stability and strength is crucial. The alloy’s ability to resist creep and rupture under extended stress guarantees a long service life in high-temperature and corrosive settings, making Incoloy 800H Forgings a top choice for many industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
