Isis Metals stands out as a top manufacturer and supplier of Super Duplex Steel S32750 Forgings, proudly based in Manila, Philippines. Known for their commitment to quality, the company produces forgings that deliver remarkable strength, durability, and resistance to corrosion. Utilizing cutting-edge forging technology and top-notch materials, these products are designed to meet global performance and reliability standards. Isis Metals offers Super Duplex Steel S32750 Forgings in a diverse range of forms and sizes, serving industries like oil and gas, chemical processing, marine engineering, and power generation, where exceptional mechanical and corrosion-resistant properties are essential.
The composition of Super Duplex Steel S32750 Forgings includes about 25% chromium, 7% nickel, 4% molybdenum, along with trace amounts of nitrogen, manganese, and tungsten. This well-balanced chemistry ensures outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. With impressive tensile strength (≥750 MPa) and yield strength (≥550 MPa), along with good ductility (elongation ≥25%), these forgings boast a dual-phase microstructure of ferrite and austenite, providing a unique blend of toughness and hardness that excels in challenging and corrosive environments.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32750 | 1.4410 | S32750 |
Yes, S32750 super duplex steel forgings are ideal for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and stress corrosion cracking.
Super Duplex Steel S32750 forgings are compatible with welding processes like GTAW (TIG), SMAW (Stick), GMAW (MIG), and SAW, using matching filler metals to ensure corrosion resistance and strength.
Limitations of S32750 forgings include susceptibility to hydrogen embrittlement, limited high-temperature performance, potential for welding-induced phase imbalance, and careful heat treatment requirements to maintain corrosion resistance and mechanical properties.
Super Duplex Steel S32750 Forgings are widely utilized in applications demanding superior strength and corrosion resistance. You’ll find them in pressure vessels, valves, shafts, pumps, flanges, and heat exchangers across marine, petrochemical, and offshore sectors. They shine in chloride-rich and acidic settings, such as seawater desalination systems and chemical processing plants. Thanks to their long-lasting durability, low maintenance needs, and resistance to localized corrosion, these forgings are the go-to choice for high-performance engineering and industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
