Isis Metals stands out as a leading manufacturer and supplier of Super Duplex Steel S32760 Forgings right in the heart of Manila, Philippines. These forgings are celebrated for their incredible strength and resistance to corrosion, making them perfect for tough environments like chemical processing, marine, and offshore industries. With a commitment to quality, Isis Metals uses advanced manufacturing techniques and top-notch materials to ensure that every forging meets international standards for durability and precision. They offer a diverse range of shapes and sizes, delivering products that not only excel in mechanical performance but also resist pitting, crevice corrosion, and stress cracking.
Super Duplex Steel S32760 Forgings are made up of about 25% chromium, 7% nickel, and 3.6% molybdenum, along with some tungsten, copper, and nitrogen. This well-balanced composition significantly boosts their corrosion resistance, particularly in environments rich in chlorides and acids. They boast impressive tensile strength (≥750 MPa), yield strength (≥550 MPa), and good elongation (≥25%). Thanks to their unique duplex microstructure of austenite and ferrite, these forgings offer an outstanding mix of toughness, hardness, and fatigue resistance, making them ideal for critical and high-pressure applications.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
You’ll find Super Duplex Steel S32760 Forgings widely used in industries that demand high strength and corrosion resistance. They’re commonly found in desalination plants, offshore oil and gas platforms, chemical processing units, pumps, shafts, valves, and heat exchangers. Their excellent resistance to pitting and crevice corrosion makes them a go-to choice for marine and seawater systems, while their robust strength ensures reliability in high-pressure and high-temperature operations. These forgings are the preferred option in environments where top-notch performance, long service life, and minimal maintenance are key.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
