Isis Metals is a reputable manufacturer and supplier located in Manila, Philippines, specializing in top-notch **Nimonic C263 Bars and Rods** tailored for demanding industrial needs. These bars and rods are crafted to provide outstanding strength, resistance to corrosion, and durability even in extreme temperatures. Thanks to cutting-edge manufacturing methods and rigorous quality control, Isis Metals guarantees products that align with international standards. The Nimonic C263 Bars and Rods from Isis Metals find their place in various industries, including aerospace, power generation, chemical processing, and marine engineering, where high performance and reliability are crucial for essential components and systems.
Nimonic C263 Bars and Rods mainly consist of nickel, chromium, and molybdenum, with added cobalt, titanium, and aluminum. This well-balanced composition ensures high-temperature strength and excellent oxidation resistance. The alloy boasts superior creep and fatigue properties, making it perfect for extended use in harsh environments. With a tensile strength of around 1000 MPa and remarkable ductility, Nimonic C263 maintains its mechanical integrity under stress and heat, ensuring reliable performance in high-pressure and high-temperature situations.
Dimension : EN, DIN, JIS, ASTM, BS, ASME, AISI
Grade : Nimonic C263 Round Bars
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Surface : Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
Application : Chemical process, Food processing, Petrochemical, Pollution control, Pulp and Paper, Refining
Condition : Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished.
Our Nimonic Alloy C263 Round Bars conforms to NACE MR0175/ISO 15156
| Nimonic Alloy 263 | 0.04-0.08 | 19 – 21 | 19 – 21 | 1.90 – 2.40 | 0.60 max | 0.40 max | 0.20 max | 0.60 max |
| Tensile strength | ISO 6892-1:2009(B) Annex D | 900 ± 40 MPa | 1100 ± 30 MPa |
| Yield strength (Rp 0.2 %) | ISO 6892-1:2009(B) Annex D | 650 ± 40 MPa | 800 ± 30 MPa |
| Elongation at break | ISO 6892-1:2009(B) Annex D | 40 ± 5 % | 35 ± 5 % |
| Young’s Modulus | – | 220 ± 15 MPa | 220 ± 15 MPa |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Nimonic Alloy 263 | 2.4650 | N07263 |
Common diameters for Nimonic C263 rods range from 3mm to 200mm, with popular sizes including 6mm, 12mm, 25mm, 50mm, and 100mm. Custom sizes are also available upon request.
Nimonic C263 rods are available in sizes ranging from 3mm to 250mm in diameter. Common finishes include hot-rolled, cold-drawn, and polished, offering versatility for various applications.
Yes, Nimonic C263 bar can be welded. It is typically welded using gas tungsten arc welding (GTAW) or gas metal arc welding (GMAW) with a matching filler material for optimal results.
Nimonic C263 Bars and Rods are widely used in **aerospace and gas turbine components**, such as combustion chambers, turbine casings, and exhaust systems. Their capacity to endure extreme heat and mechanical stress also makes them suitable for **power generation**, **chemical processing**, and **marine industries**. These bars and rods are essential in producing fasteners, shafts, and high-performance engine parts where durability and corrosion resistance are vital. The exceptional strength and stability of Nimonic C263 under high temperatures make it a go-to material for engineering applications that require reliability and long-lasting performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
