Isis Metals stands out as a top manufacturer and supplier of Maraging Steel Bars and Rods, proudly based in Manila, Philippines. The company is dedicated to crafting high-quality, high-strength steels that are renowned for their remarkable toughness, dimensional stability, and resistance to wear and fatigue. Using cutting-edge metallurgical techniques and top-notch raw materials, their Maraging Steel Bars and Rods adhere to international standards for precision, durability, and performance. Isis Metals offers these bars and rods in a variety of sizes and finishes, catering to industries like aerospace, defense, tooling, automotive, and high-performance engineering, where exceptional mechanical properties are a must.
These Maraging Steel Bars and Rods are primarily made of iron, containing 18–25% nickel, along with trace amounts of cobalt, molybdenum, titanium, and aluminum. This unique blend gives the alloy impressive tensile strength of up to 2000 MPa, remarkable hardness (up to 60 HRC after aging), and outstanding toughness and ductility. The innovative maraging process allows the steel to achieve high strength without a significant carbon content, which reduces brittleness and enhances machinability and weldability.
| Standard : | AMS, AMS, API |
| Specification : | ASTM A538, AMS 6512, Mil-S-46850D, BS S162, DTD 5212, MSRR 6551, MAT 102, MIA 101 |
| Size : | 20mm x 1200 x 500 |
| Specialize Sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Maraging Steel 250/ 300 / 350 (UNS-K92890, K93120, S35000) |
| Grade | C | Mn | Si | Co | Fe | Ni | Mo | Ti | Al |
| Maraging C250 | .03max max | .10max max | .10max max | 7.50 max | Bal | 18.50 min | 4.80 max | .40 max | .10 max |
| Maraging C300 | .03max max | .10max max | .10max max | 9.0 max | Bal | 18.50 min | 4.80 max | .60 max | .10 max |
| Maraging C350 | .03max max | .10max max | .10max max | 12.0 max | Bal | 18.50 min | 4.80 max | 1.40 max | .10 max |
| Grade | Density | Average Coefficient of Thermal Expansion | Modulus of Elasticity |
| Maraging 250 | .289 lbs./cu.in | 5.6 x 10-6 in./ in./ ºF | 5.6 x 10-6 in./ in./ ºF |
| Maraging 300 | .289 lbs./cu.in | .289 lbs./cu.in | 292 lbs./cu.in |
| Maraging 350 | .289 lbs./cu.in | 6.3 x 10-6 in./ in./ ºF | 29.0x 10-6 psi |
| STANDARD | UNS | Material No | AMS | ASTM | Mil-S | BS | DTD | MSRR |
| Maraging Steel | K92890, K93120, S35000 | – | 6512 | A538 | 46850D | S162 | 5212 | 6551 |
Maraging Steel Rods are typically available in sizes ranging from 0.125 inches (3.175 mm) to 12 inches (305 mm) in diameter, with lengths varying from 12 inches (300 mm) to 20 feet (6 meters).
Yes, Maraging steel bars can be welded, but they require careful control of heat input and pre/post-weld heat treatment to avoid compromising the material’s strength and toughness.
Maraging steel rods are typically available in diameters ranging from 0.25 inches to 8 inches. Common finishes include cold drawn, polished, or ground, with standard lengths between 12 and 24 feet.
You’ll find Maraging Steel Bars and Rods in a variety of applications, including aerospace structural components, rocket motor cases, high-performance gears, tooling dies, shafts, and precision engineering parts. Their exceptional combination of strength, toughness, and dimensional stability makes them perfect for critical applications that face high stress or impact. These bars and rods promise a long service life, reliability, and top-notch performance, making them the go-to choice for industries that demand high-strength, wear-resistant, and precision-engineered steel.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
