Isis Metals stands out as a top manufacturer and supplier of RENE 41 Bars and Rods in Manila, Philippines. They specialize in premium-grade nickel-based superalloys designed to withstand extreme temperatures and stress. Renowned for their remarkable high-temperature strength, corrosion resistance, and oxidation stability, RENE 41 Bars and Rods find their place in tough industrial settings. Isis Metals is committed to precision manufacturing, rigorous quality assurance, and adherence to international material standards. These bars and rods are perfect for high-performance applications in aerospace, power generation, and chemical processing, where durability, heat resistance, and mechanical integrity are essential for optimal performance.
RENE 41 Bars and Rods are mainly made up of Nickel (around 55%), Chromium (19%), Cobalt (11%), Molybdenum (10%), Titanium (3%), and Aluminum (1.5%), along with some trace elements. This alloy boasts impressive high-temperature strength, reaching up to 980°C (1800°F), along with excellent resistance to oxidation and creep. Its mechanical properties include a tensile strength of about 1240 MPa, yield strength of 965 MPa, and hardness of up to 350 HB. The alloy remains stable even under prolonged thermal exposure, providing outstanding fatigue and rupture strength, making it a top choice for demanding aerospace and industrial applications.
| Standards : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Thickness : | Range from .008″ to .0125″ |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Form : | Bar, Rod |
| Tungsten Grades | HA 190 / HA 1925 / HA 195 / HE 390 / HE 3925 / HE 395 / HE 397 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
Yes, RENE 41 bar can be welded using suitable techniques like gas tungsten arc welding (TIG) or gas metal arc welding (MIG). Preheating and post-weld heat treatment are recommended for optimal results.
RENE 41 bars are available in sizes ranging from 6mm to 250mm diameter, with finishes including hot-rolled, cold-drawn, rough-turned, centerless ground, and polished options.
Yes, RENE 41 rods are susceptible to galvanic corrosion when coupled with dissimilar metals in an electrolyte, especially if the other metal is more anodic. Proper isolation is recommended.
RENE 41 Bars and Rods are widely utilized in the aerospace, gas turbine, and power generation sectors due to their exceptional strength and oxidation resistance at high temperatures. They are frequently found in jet engine components, turbine blades, afterburner parts, exhaust systems, fasteners, and high-temperature springs. In chemical processing facilities, RENE 41 is prized for its ability to resist oxidation and corrosion in harsh environments. The alloy’s capacity to maintain mechanical integrity under extreme stress makes it an ideal candidate for rocket engines and high-performance applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
