Isis Metals, based in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality Stainless Steel 440C Hex Bars. These bars are celebrated for their remarkable hardness, wear resistance, and strength. Designed to meet the highest industrial standards, they’re perfect for precision components and mechanical applications that demand durability and reliability. Thanks to cutting-edge manufacturing technology and rigorous quality control, Isis Metals guarantees consistent performance and precise dimensions. The Stainless Steel 440C Hex Bar is well-known for its excellent corrosion resistance, high carbon content, and its ability to maintain a sharp edge even in tough working conditions.
Stainless Steel 440C Hex Bar is primarily made up of chromium (16–18%), carbon (0.95–1.20%), along with manganese, silicon, molybdenum, and trace elements that boost its mechanical and corrosion-resistant qualities. It boasts a high tensile strength of around 760 MPa and can reach a hardness of up to 60 HRC when heat-treated. This alloy is known for its outstanding wear resistance, good dimensional stability, and moderate corrosion resistance in mild environments. Its high carbon content contributes to superior hardness and edge retention, making it ideal for components that face friction, stress, or impact.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 440C | 1.20-0.95 | 18.00-16.00 | 1.00 | 1.00 | 0.04 | 0.03-0.15 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Heat treatment of SS 440C involves hardening by quenching and tempering, significantly increasing hardness and wear resistance. Proper heat treatment also enhances corrosion resistance, making the material suitable for demanding applications.
SS 440C Hex Bar is commonly used in bearings, shafts, valves, and tools. Its high hardness, wear resistance, and moderate corrosion resistance make it preferred over other stainless steels for demanding, high-strength applications.
Stainless Steel 440C Hex Bars find extensive use in industries that need components combining high hardness with moderate corrosion resistance. They are commonly used in the production of bearings, valve components, pump shafts, surgical instruments, nozzles, and precision tools. These hex bars are also essential in the aerospace, automotive, and defense sectors for creating wear-resistant parts and mechanical assemblies. With their excellent polishability and strength, 440C Hex Bars are perfect for cutlery, molds, and dies. Their ability to endure high stress and maintain sharpness makes them invaluable in both industrial and engineering applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
