Isis Metals stands out as a top manufacturer and supplier of Stainless Steel 304L Hex Bars and Rods right in Manila, Philippines. We pride ourselves on delivering high-quality stainless steel products that are designed for strength, precision, and resistance to corrosion. Our hex bars and rods are crafted using cutting-edge processes and adhere to international quality standards, guaranteeing reliability and durability. Known for their excellent weldability, formability, and resistance to oxidation and chemical corrosion, our Stainless Steel 304L Hex Bars and Rods serve a variety of industries, including construction, food processing, petrochemical, and marine engineering, ensuring they perform exceptionally well in both structural and industrial applications.
When it comes to composition and mechanical properties, our Stainless Steel 304L Hex Bars and Rods are made up of chromium (18–20%), nickel (8–12%), and a low carbon content (≤0.03%). This unique blend prevents carbide precipitation during welding and boosts corrosion resistance. They boast a tensile strength of about 485 MPa and a yield strength of around 170 MPa, along with impressive ductility, elongation, and toughness. The material is highly resistant to oxidation, acids, and chloride environments, all while maintaining mechanical stability under thermal stress. The combination of low carbon and a well-balanced alloy composition makes our 304L Hex Bars and Rods perfect for fabrications that demand both strength and corrosion protection.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 | 170 | 40 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 304L hex bars/rods are typically available in sizes ranging from 3.17mm to 350mm in diameter, with lengths of 2 to 7.5 meters. These bars come in various finishes, such as polished or cold-drawn. Custom sizes and specifications can also be produced upon request to meet specific needs.
Yes, SS 304L hex bars/rods are highly weldable and suitable for fabrication into complex shapes. Their low carbon content minimizes carbide precipitation during welding, reducing the risk of corrosion. This material's excellent ductility and toughness allow easy forming, machining, and fabrication, making it ideal for intricate designs and applications.
SS 304L has lower carbon content than standard 304, reducing carbide precipitation and enhancing corrosion resistance, particularly after welding. While slightly lower in strength compared to higher-carbon grades like 304 or 316, it maintains excellent toughness and durability. SS 316 offers superior corrosion resistance in chloride environments due to added molybdenum.
Stainless Steel 304L Hex Bars and Rods find their place in various industries that need robust, corrosion-resistant materials with outstanding weldability and machinability. They are particularly well-suited for chemical processing, food and beverage production, pharmaceutical equipment, and marine structures. Additionally, these hex bars are utilized in architectural frameworks, fasteners, shafts, and valves where strength and durability are crucial. Their exceptional resistance to oxidation and intergranular corrosion makes them ideal for welded components.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
