Isis Metals is a well-respected manufacturer and supplier of Stainless Steel Polished Bars and Rods, proudly based in Manila, Philippines. They’re known for delivering top-notch polished bars and rods that stand out for their impressive surface finish, durability, and resistance to corrosion and oxidation. Made from high-quality stainless steel and utilizing modern polishing techniques, these products adhere to international quality and performance standards. Isis Metals offers a diverse selection of sizes, shapes, and finishes to meet the needs of various industries, including construction, marine, food processing, and architectural design.
The composition of Stainless Steel Polished Bars and Rods primarily includes iron, chromium (16–26%), nickel (6–22%), and molybdenum, depending on the specific grade like 304, 316, or 410. This blend gives them remarkable resistance to rust, pitting, and scaling in different environments. On the mechanical side, they boast high tensile strength (520–750 MPa), yield strength (205–550 MPa), along with good ductility and hardness. The polished surface not only boosts their visual appeal but also provides excellent protection against corrosion and wear, ensuring they perform reliably over time.
Standards : ASTM A276, ASTM A484, AISI
Grade : 201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
Range : from 2.00mm to 6.35mm (0.078″ to 0.25″)dia.
Tolerance : DIN 671, ASTM A484 & as per customer’s specific requirement.
Finish : Cold drawn, Centreless Ground, Polished
| Grade | Su | C | Si | P | Cr | Ni | M | Mo | Other |
|---|---|---|---|---|---|---|---|---|---|
| 316 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 16.0-18.0 | 10.0 14.0 | 2.00 max | 2.0 3.0 | – |
| 317L | 0.030 max | 0.035 max | 0.75 max | 0.045 max | 18.0-20.0 | 11.0 14.0 | 2.00 max | 3.0 4.0 | – |
| 304 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 18.0-20.0 | 8.0 11.0 | 2.00 max | – | – |
| 310 S | 0.030 max | 0.08 max | 1.5 max | 0.045 max | 24.0-26.0 | 19.0 22.0 | 2.00 max | 3.0 4.0 | – |
| 347 H | 0.030 max | 0.04 0.10 | 0.75 max | 0.045 max | 17.0- 19.0 | 9.0 13.0 | 2.00 max | – | 10C(Cb+Ta)<1.10% |
| 321 | 0.030 max | 0.08 | 0.75 max | 0.045 max | 17.0-20.0 | 9.0 12.0 | 2.00 max | – | 5C 0.70% |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Density | Elongation | Melting Point |
|---|---|---|---|---|---|
| SS 303 | Psi – 85,000 | Psi – 45,000 | 55% | 50 % | Rb 180 |
| SS 202 | 515 MPa | 275 MPa | 8.0 g/cm3 | 40 % | 1454 °C |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 35 % | 1454 °C |
| SS 316L | 485 Min | 170 Min. | 8.0 g/cm3 | 40 % | 1400 °C |
The typical lifespan of stainless steel polished bars ranges from 20 to 100 years, depending on environmental conditions, maintenance, and alloy composition, with excellent corrosion resistance ensuring long-term durability.
Yes, stainless steel polished bars and rods can be customized in size. Manufacturers offer various diameters, lengths, and finishes to meet specific project requirements, ensuring tailored solutions for different applications.
Yes, stainless steel polished bars and rods can be welded. Techniques like TIG or MIG welding are commonly used, though surface preparation is essential to maintain the polished finish and ensure strong welds.
These Stainless Steel Polished Bars and Rods find their way into a variety of industries for both functional and decorative uses. You’ll often see them in architectural frameworks, railings, furniture, and automotive parts, where both appearance and strength matter. Additionally, they’re essential in food processing, marine, chemical, and pharmaceutical sectors due to their hygienic surfaces and corrosion resistance. These polished bars and rods are perfect for machinery parts, shafts, fasteners, and construction supports, delivering outstanding performance even in tough conditions while ensuring durability, easy maintenance, and a sleek look.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
