Isis Metals stands out as a top manufacturer and supplier of Stainless Steel 317L Hex Bars and Rods right here in Manila, Philippines. We pride ourselves on delivering precision-engineered products that excel in highly corrosive environments. Our 317L Hex Bars and Rods are celebrated for their remarkable resistance to chemical attacks and pitting corrosion, thanks to their high molybdenum and low-carbon content. Crafted to meet international standards, these bars and rods boast exceptional mechanical strength, toughness, and weldability. Industries like chemical processing, pharmaceuticals, food processing, and marine applications rely on Isis Metals for durable and corrosion-resistant solutions.
Stainless Steel 317L Hex Bars and Rods are made up of chromium (18–20%), nickel (11–15%), molybdenum (3–4%), carbon (≤0.03%), along with trace amounts of manganese, silicon, and nitrogen. The low-carbon variant of 317 stainless steel provides outstanding resistance to intergranular corrosion and harsh chloride environments. They showcase a tensile strength of about 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. With excellent creep strength, ductility, and oxidation resistance, these hex bars and rods are perfect for demanding industrial and marine applications that involve high pressure and temperature.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317l | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317l | 8 | 1450 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317L Hex Bars/Rods are commonly used in chemical processing, marine environments, pharmaceuticals, and food processing due to their excellent corrosion resistance and high strength. They are ideal for handling aggressive chemicals, including sulfuric acid, bleaching solutions, and pulp liquor. In construction, they are used for structural components and fittings.
SS 317L Hex Bars/Rods typically range from 6 mm to 100 mm in diameter, with lengths up to 6 meters. Tolerances generally conform to ±0.5 mm for diameter. These dimensions and tolerances ensure precision for machining, making them ideal for applications requiring high strength, corrosion resistance, and tight fit.
The high chromium (18-20%) and molybdenum (3-4%) content in SS 317L enhances its resistance to pitting and crevice corrosion by forming a passive oxide layer that protects against chloride-induced degradation. The low carbon content further reduces the risk of stress corrosion cracking, ensuring durability in harsh chloride environments.
You’ll find Stainless Steel 317L Hex Bars and Rods widely used across various sectors, including chemical processing, marine engineering, paper and pulp production, food processing, and pharmaceuticals, all thanks to their exceptional corrosion resistance and durability. They’re perfect for equipment like evaporators, heat exchangers, condensers, and reactor vessels that face aggressive chemicals and saline environments. Plus, these bars and rods are utilized in pump shafts, fasteners, and structural components that require high strength and stability. Their superior formability, weldability, and resistance make them a go-to choice for many applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
