Isis Metals is a well-respected manufacturer and supplier located in Manila, Philippines, focusing on top-notch Aluminium 6082 Bars and Rods. The company has built a solid reputation for its precision engineering, reliability, and dedication to providing products that adhere to international standards. Aluminium 6082 is a medium-strength, heat-treatable alloy celebrated for its outstanding corrosion resistance, good machinability, and excellent weldability. At Isis Metals, advanced manufacturing technology and strict quality control measures are in place to guarantee that every Aluminium 6082 bar and rod delivers consistent mechanical performance, durability, and a long service life for various industrial, structural, and marine applications.
Aluminium 6082 Bars and Rods mainly consist of aluminum, with magnesium (0.6–1.2%) and silicon (0.7–1.3%) as the primary alloying elements, along with trace amounts of manganese, chromium, and iron. This specific composition results in high tensile strength, typically ranging from 250 to 340 MPa, and remarkable corrosion resistance in both marine and industrial settings. The alloy also boasts good formability and excellent weldability, making it a favored choice for structural components. It’s often dubbed a “structural alloy” because of its strength and toughness across various tempers.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Ti | Other Each | Others Total |
| Aluminium 6082 | Bal | 0.7 – 1.3 | 0.50 max | 0.10 max | 0.40-1.00 | 0.25 max | 0.06-1.20 | 0.20 max | 0.10 max | 0.05 max | 0.15 max |
| Diameter or minor sectional dimension mm | Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % |
| 0-20 | 295 | 255 | 8 |
| 20-150 | 310 | 270 | 8 |
| 150-200 | 280 | 240 | 5 |
| UNS | EN | DIN | ISO | BS (OLD) | USA | WNR |
| A96082 | AW-6082 | AlMgSi1 | Al Si1MgMn | HE30 | AA6082 | 3.2315 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6082 rods can be customized in size and length based on specific requirements. Manufacturers often offer custom dimensions to suit various industrial and structural applications.
Yes, Aluminium 6082 bars can be used underground due to their corrosion resistance and strength. However, proper coatings or anodization may be needed to enhance durability in highly corrosive environments.
Yes, Aluminium 6082 bars are fully recyclable. Aluminium is highly sustainable, retaining its properties through multiple recycling processes, making it an eco-friendly material for various applications.
Aluminium 6082 Bars and Rods find extensive use in structural, transportation, and marine applications that demand a blend of strength and corrosion resistance. You’ll commonly see them in bridges, cranes, trusses, and architectural frameworks. In the automotive and marine sectors, they’re utilized for chassis, frames, and ship components. This alloy is also ideal for crafting machinery parts, pressure vessels, and pipelines. With its perfect balance of strength, weldability, and corrosion resistance, Aluminium 6082 stands out as one of the most versatile and widely used aluminum alloys in engineering and construction.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
