Isis Metals stands out as a reliable manufacturer and supplier of Inconel 738 Bars and Rods right in Manila, Philippines. They specialize in high-quality superalloys that are built to withstand extreme service environments. Inconel 738, a nickel-based superalloy, is well-known for its impressive resistance to oxidation, corrosion, and creep at high temperatures. Isis Metals crafts these Inconel 738 Bars and Rods with precision, making them perfect for high-stress applications in industries like aerospace, power generation, and petrochemicals. With a strong focus on top-notch metallurgy, dimensional accuracy, and adherence to international quality standards, Isis Metals guarantees that their products perform reliably even in the toughest thermal and mechanical conditions, including harsh oxidizing or corrosive environments.
Inconel 738 Bars and Rods are primarily made up of Nickel (Ni 60–70%), Chromium (Cr 15.5–16.5%), Cobalt (Co 8.0–9.0%), Titanium (Ti 3.2–3.7%), Aluminum (Al 3.2–3.7%), Tungsten (W 2.4–2.8%), along with trace elements like Tantalum and Boron. These components work together to provide outstanding tensile strength (up to 1000 MPa), impressive hardness, and excellent creep rupture resistance at temperatures above 980°C. The alloy also boasts superior oxidation and thermal fatigue resistance, ensuring long-lasting performance even under severe thermal cycling and stress. Inconel 738 maintains high stability and mechanical integrity across a wide range of environments.
Specification : ASTM B 166 / ASME SB 166
Dimensions : ASTM, ASME and API
Size : 5 mm To 500 mm Dia in 100 mm TO 6000 mm Length available with NACE MR 01-75.
Length : 100 mm To 3000 mm Long & Above
Finish : Bright, Polish & Black
Grade : Inconel 738 – UNS N07738
Form : Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Our Inconel 738 Round Bars conforms to NACE MR0175/ISO 15156
| Appearance | Metallic powder or solid in various forms |
|---|---|
| Melting Point | 1230-1315 °C |
| Boiling Point | N/A |
| Density | 8.11 g/cm3 |
| Solubility in H2O | N/A |
| Specific Heat | 0.10 Btu/lb/° F (70 ° F) |
| Tensile Strength | 159000 psi (70 °F) |
| Thermal Conductivity | 82 Btu/ft2/in/hr/°F (400 °F) |
| Thermal Expansion | 6.45 x 10-6 (70-200 °F) |
Inconel 738 bars and rods are not typically used in cryogenic applications, as their properties are optimized for high-temperature environments. For cryogenic conditions, alloys specifically designed for low temperatures are preferred.
To choose the right Inconel 738 bars and rods, consider factors such as temperature requirements, corrosion resistance, mechanical strength, specific application needs, and compatibility with other materials in the operating environment.
Yes, Inconel 738 bars and rods should undergo regular inspection, especially in high-stress and high-temperature applications, to ensure they maintain their structural integrity and performance over time.
Inconel 738 Bars and Rods find extensive applications in the aerospace, gas turbine, and energy sectors, where high-temperature strength and oxidation resistance are essential. They are perfect for crafting turbine blades, vanes, exhaust ducts, combustion liners, and components for jet engines that face extreme heat and corrosive gases. In the power generation field, they are utilized in superheater tubes, furnace parts, and heat exchangers. The chemical processing industry also relies on them for reactor components, valves, and fasteners that are exposed to aggressive media.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
