Isis Metals is a reputable manufacturer and supplier located in Manila, Philippines, specializing in high-quality Titanium Grade 1 Bars and Rods for a variety of industrial uses. Renowned for our precision engineering, durability, and dependability, our products adhere to international performance and quality standards. Titanium Grade 1 Bars and Rods are prized for their outstanding corrosion resistance, excellent ductility, and weldability, making them perfect for challenging environments. We serve industries such as chemical processing, marine, aerospace, and medical manufacturing, consistently delivering quality, timely service, and cost-effective solutions to clients both in the Philippines and around the world.
Titanium Grade 1 Bars and Rods are made from commercially pure titanium (at least 99.5% Ti) with small amounts of oxygen, nitrogen, carbon, hydrogen, and iron. This grade is known for its remarkable corrosion resistance, high impact toughness, and superior ductility. It boasts a tensile strength of approximately 240–370 MPa, a yield strength of 170 MPa, and a density of 4.51 g/cm³. With a melting point of 1660°C, Titanium Grade 1 remains stable even under extreme temperatures. Its excellent weldability and formability make it an ideal choice for creating lightweight, corrosion-resistant components.
| Standards : | ASTM B348, B863 / ASME SB 348, SB 863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 1 | 3.7025 | R50250 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | 0.08 max | 0.03 max | 0.18 max | 0.015 max | Bal | 0.20 20 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 240 | 170 | 24 % |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 1 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@isismetals.com
Titanium Grade 1 Bars and Rods find extensive use in industries that demand high corrosion resistance and formability. In the chemical processing sector, they are utilized for heat exchangers, reaction vessels, and piping systems that deal with corrosive materials. The marine industry employs them in desalination plants, ship components, and offshore structures. In aerospace and medical applications, they are essential for aircraft parts, surgical instruments, and implants due to their strength, lightweight nature, and biocompatibility. Additionally, they are used in power generation and electroplating applications, where durability is crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
