Isis Metals, a top-notch supplier of specialty metals based in Manila, Philippines, offers robust **Titanium Grade 4 Bars and Rods** tailored for tough industrial, medical, and marine applications. Renowned as the strongest among commercially pure titanium grades, Grade 4 boasts remarkable corrosion resistance, excellent formability, and outstanding performance even in the harshest conditions. Isis Metals provides precisely manufactured bars and rods in a variety of diameters and lengths, all adhering to international standards. With a reliable supply chain, competitive pricing, and a commitment to quality, Isis Metals stands out as a trusted partner for those in need of durable, high-strength titanium solutions for critical, long-lasting applications.
Titanium Grade 4 is composed of 99.2% titanium, with trace amounts of oxygen (0.40%) and iron (0.50%). It offers the highest strength among commercially pure titanium grades, featuring a tensile strength of about 550 MPa (80,000 psi) and a yield strength of roughly 483 MPa (70,000 psi). Despite its impressive strength, Grade 4 maintains good ductility and excellent corrosion resistance, particularly in environments rich in chlorides, acids, or marine conditions. It’s non-magnetic, lightweight, and biocompatible. While this grade isn’t heat-treatable, it can be cold-formed and welded, making it perfect for fabrications that demand strength without compromising on corrosion resistance or precision.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 4 | 3.7065 | R50700 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 4 | 0..08 max | 0.05 max | 0.40 max | 0.015 max | Bal | 0.50 max |
| Tensile Strength | Reduction of area | Elongation | Hardness |
| 552 | 25 % | 15 % | 100 |
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat (BTU/lb-°F) | Thermal expansion (1/°F) | Melting Point (°F) |
| 0.163 | 2.87 | 119 | 0.127 | 0.00000478 | 3020 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 4 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@isismetals.com
Titanium Grade 4 Bars and Rods are composed of 90% titanium, 6% aluminum, and 4% vanadium, offering excellent strength, corrosion resistance, and durability.
Yes, Titanium Grade 3 has good weldability, making it suitable for various applications where welding is required.
Titanium Grade 4 Bars and Rods find extensive use in industries that require a strong, corrosion-resistant, and biocompatible material. In the medical sector, they are utilized for orthopedic implants, dental fixtures, and surgical tools. In marine applications, they are ideal for shafts, fasteners, and underwater structures that face challenging conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Isis Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Manila, Philippines
